Small Extracellular Vesicles, or EVs, which measure between 30 and 150 nm in diameter (including exosomes), are naturally released by most living cells. They play a significant role in both physiological and pathological processes, enabling the transfer of information from donor cells to recipient cells. These vesicles carry a variety of cargoes, such as proteins, RNAs, lipids, and DNA, which can be taken up by other cells.
The bioengineering of EVs is facilitated by Ciloa technology, which employs an active sorting mechanism to incorporate any desired protein into the EVs produced by eukaryotic cells, utilizing a proprietary Pilot Peptide (PP) that is patented. This PP interacts with the ESCRT machinery to effectively sort the protein of interest into the EVs. A synthetic DNA sequence, optimized for coding the target protein, is linked to the PP, and the resulting chimeric gene is cloned into Ciloa's proprietary vector. This vector allows for the transcription of mRNA that encodes the chimeric protein in eukaryotic cells. The stable transfection of HEK293T cells results in the expression of the target protein within the EVs.
Fully native proteins conformation
without being hindered by a grafting on an EV protein (e.g. CD63)
Proteins embedded at the EVs surface or in the lumen
Cargo or membrane proteins
Functional hetero-oligomers of membrane protein complexes can be sorted on EVs.
(e.g. hetero-octamer of an ion channel)
Not interfere with regular EVs proteins
(e.g. tetraspanins)
We offer 3 types of Small Extracellular Vesicles
Standard EVs
Standard EVs are native EVs, produced by non-modified cells. These EVs are interesting tools that can be used for data normalisation, EV instrument calibration or as a control, either positive or negative, in EV quality controls, EV characterisation, functional assays, etc.
Fluorescent EVs
Labelled EVs bioengineered with internal cargoes are customised using Ciloa technology which does not overexpress and has no interaction with regular EV surface proteins like tetraspanins. These EVs can be used for data normalisation, purification process internal standard, instrument calibration and cell fluorescence imaging.
- mCerulean EVs
- EGFP EVs
- CyOFP1 EVs
Bioengineered EVs
EVs bioengineered with fully native membrane proteins can harbour any kind of protein like G-protein coupled receptors (GPCR), kinase receptors, ion channels or soluble proteins, fused to a transmembrane domain to anchor them in the EV membrane. They can be use to study molecular interactions with ligands, specific antibodies or small molecules.
- ALK-2 EVs
- ALK-4 EVs
- CCR-10 EVs
- CCR-7 EVs
- MISRII
Specifications
Particule size (nano-flow cytometry) : Median size of 60-70 nm
Source : HEK293T
Buffer : PBS 1X-BSA 10µg/mL
Lifetime: up to 12 months (Standard EVs), up to 6 months (Fluorescent and Bioengineered EVs)
Storage: Store sterile at +4°C
Standard EVs
Standard EVs are native EVs, produced by non-modified cells.
EGFP EVs
EGFP EVs are bioengineered EVs, loaded with EGFP, enhanced green fluorescent protein in their lumen.
mCerulean EVs
mCerulean EVs are bioengineered EVs, loaded with mCerulean cyan fluorescent protein in their lumen.
CyOFP1 EVs
CyOFP1 EVs are bioengineered EVs, loaded with CyOFP1 cyan-excitable orange fluorescent protein in their lumen.
CCR-10 EVs
CCR-10 EVs are bioengineered EVs, harbouring human CCR-10 (human C-C chemokine receptor type 10) GPCR at their surfac
CCR-7 EVs
CCR-7 EVs are bioengineered EVs, harbouring human CCR-7 (human C-C chemokine receptor type ) GPCR at their surface.
ALK-2 EVs
ALK-2 EVs are bioengineered EVs, harbouring human ALK-2 receptor (human Activin receptor-like kinase 2) at their surface.
ALK-4 EVs
ALK-4 EVs are bioengineered EVs, harbouring human ALK-4 receptor (human Activin receptor-like kinase ) at their surface.
MISRII EVs
MISRII EVs are bioengineered EVs, harbouring human MISRII receptor (Muellerian inhibiting substance type II receptor) at their surface
